MULTI-TASKER
9
S = saves command to memory
Example:
[ON1VG1U1] : Turns ON C-Video input 1 for
each card in group 1 of unit 1.
[ON…..P]: sets path
This command will set the path for the output,
but it is not active until the switch command,
[SW], is executed. Commands ending in "P"
are not executed immediately. The Path for
outputs may be set on a single card or for
multiple cards. In either case, all Paths will be
switched when the [SW] command is executed.
Command Formats:
[ONmVCnUiP] and
[OnmSCnUiP]
m = Input number (m = 1 to 4)
(input 4 is internal)
S = activates S-Video input
V = activates C-Video input
Cn = card ID (n = slot # from 1 to max slots)
P
= path
Example:
There are two MT104-107 cards in slot 6 and 7
of unit 3. Enable S-Video input 1 of card 6 and
S-Video input 3 of card 7 simultaneously. Use
the following commands:
[ON1SC6U3P]
[ON3SC7U3P]
[SW]
If "F" is included, use the [ONmCnUiPF]
command or the [ONmCnUiFP]
command.
[ON…..F]: feedback
After processing a command, an OK or ER will
be returned as feedback if "F" is included at the
end of a command string.
Example:
[ON1VC2U3F]: if path is not set
[ON1VC2U3PF]: if path is set
5. [OFF]
This command disables one input of a single
card or a group of cards.
SINGLE CARD
[OFFmVCnUiS] for Composite Video
[OFFmSCnUiS] for S-Video
This command disables input “m” or all inputs.
[OFFVC5CnUi]: Turns OFF all C-Video inputs
of the MT104-107 card.
m = Input number (m = 1 to 4)
(input 4 is internal)
Cn = Card ID (n = slot # from 1 to max slots)
Ui
= Unit ID number (i = 0 to 9)
S = activates S-Video input
V = activates C-Video input
S = saves command to memory
Example:
Card 5 of unit 3 has S-Video input 1 and
C-Video input 2 ON. The following commands
can be used to turn OFF the inputs.
1) [OFF1SC5U3] or [OFFSC5U3] : Turns OFF
S-Video input.
2) [OFFVC5U3]: Turns OFF C-Video input.
GROUP OF CARDS
[OFFmVGkUiS] for Composite Video
[OFFmSGkUiS] for S-Video
This command disables input "m" for each card
in group "k" of unit "i".
m = Input number (m = 1 to 4)
(input 4 is internal)
Cn = Card ID (n = slot # from 1 to max slots)
Ui
= Unit ID number (i = 0 to 9)
S = activates S-Video input
V = activates C-Video input
S = saves command to memory
Example:
1) [OFF1SG1U1] : Turns OFF S-Video input 1
for each card in group 1 of unit 1.
2) [OFF1VG1U1] : Turns OFF C-Video input 1
for each card in group 1 of unit 1.
