41
APPENDIX C. TROUBLESHOOTING GUIDE
REQUIREMENTS
• Personal Computer.
• RS232 cable, P/N 22517507 or 22517509.
• AC adapter, P/N 64300050.
• SET-MICR program, P/N 22000020.
• Sample checks, P/N 96530005.
• A small bottle of compressed air.
• A cleaning card, P/N 96700006.
SET-UP
1. Plug the 9-pin din connector of the RS232 cable into the MICR Reader.
2. Plug the DB25 or DB9 connector of the RS232 cable into the PC.
3. Power on the MICR Reader.
4. Run the SET-MICR program on the PC.
5. Press to establish communication between the PC and the MICR Reader.
6. Start trouble-shooting procedure at Step 00.
00 CHECK
LED
Check the status of the LED indicator:
◊ off, continue to step 01.
◊ green, continue to step 02.
◊ blinking red, continue to step 11.
◊ blinking green, continue to step 16.
◊ blinking red/green, continue to 12.
◊ red or orange, continue to step 17.
