MiniWedge Swipe Reader
2
RELATED DOCUMENTS
MagTek Device Drivers For Windows, Programming Reference Manual, P/N 99875125.
SPECIFICATIONS
Table 1-1. Specifications
OPERATING
Reference Standards ISO/ANSI/ CDL/ AAMVA
Recording Method Two-frequency coherent phase (F2F)
Message Format Scan Code
Card Speed 3 to 50 IPS
Track Format Reads 75-210 bpi on all 3 tracks
MTBF Electronics: 125,000 hours. Head: 1,000,000 passes
ELECTRICAL
Power Input From PC: 5VDC; power supplied by keyboard interface
Current 20 mA max
MECHANICAL
Dimensions Length 3.94” (100.0 mm)
Width 1.28” (32.5 mm)
Height 1.23” (31.3 mm)
Weight, Reader only 5.8 oz. (165 gr.)
Reader with Cable 6.5 oz. (184 gr.)
Cable length 6 Ft. (1.8 m)
Connectors 6-pin Mini Din and 5-pin Din; includes adapter cable
ENVIRONMENTAL
Temperature
Operating 32
o
F to 131
o
F (0
o
C to 55
o
C)
Storage -22
o
F to 158
o
F (-30
o
C to 70
o
C)
Humidity
Operating 10% to 90% noncondensing
Storage Up to 100% noncondensing
Altitude
Operating 0-10,000 ft. (0-3048 m.)
Storage 0-50,000 ft. (0-15240m.)
