MiniWedge Swipe Reader
18
NBR 0 – Send numbers (top of keyboard)
1 – Send numeric keypad
LC 0 – Send card data as upper case
1 – Send card data as lower case
Er 00 – Don’t send any card data if error
01 – Don’t send track data if error
11 – Send ‘E’ for each track error
Default: 0x63 = send SS and ES, all upper case, send [SS]E[ES] for each track error.
P022 Terminating Char
mod c c c c c c c
mod 0 – Send c after card data
1 – Send c after each track
c 1-127 – 7 bit ASCII char code
0 – send nothing
Note: 0x80 sends a "NUL" as ^@.
Default: 0x0D = Carriage return at the end of full card message.
P02A Hardware Track Mapping
In some cases, it may be desirable to read a certain track format on a different physical track. The track
mapping parameter allows the electronics to be set so that track 1 data, for example, can be read from the
track 2 position. The table below indicates how the tracks can be mapped.
Hardware track 1 2 3
Map value
0 1 2 3
1 3 2 1
2 2 1 3
3 1 3 2
4 2 3 1
5 3 1 2
