Section 4. USB Communications
37
PAN NAME DATE ENABLE PROPERTY
Property ID:
0x1D
Property Type: Byte
Length: 1 byte
Get Property: Yes
Set Property: Yes
Default Value: 0 (DISABLED)
Description:
When this property is set to 0, the reader data transmission will use the
standard mode of sending track information as described in SECTION 4.
When this value is set to non-zero, and Track 1 or Track 2 is determined to be
in a financial data format, the reader will transmit the PAN (Primary Account
Number), Name and Expiration date using the following format:
If Track 1 is available:
Track 2 data will not be transmitted
If only Track 2 is available:
If Track 1 and Track 2 are not in financial data format or cannot be decoded,
the reader will revert back to standard mode.
This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled to have these changes take effect.
Rules used for determining that a card is in financial data format:
• PAN length should be between 13 and 19
• Name length should be between 0 and 26 characters for Track 1
• Only 2 field separators (‘^’) for Track 1
• Only 1 field separator (‘=’) for Track 2
• Format code shall be the character ‘B’ for Track 1
Example Set PAN Name Date Enable property to 01 Request (Hex):
Cmd Num Data Len Prp ID Prp Value
01 02 1D 01
Example Set PAN Name Date Enable property Response (Hex):
Result Code Data Len Data
00 00
Example Get PAN Name Date Enable property Request (Hex):
Cmd Num Data Len Prp ID
00 01 1D
