43-Millimeter Compatible Swipe Reader
4
CONNECTORS
Single Track I/O Connector is shown in Table 2-1, and the Dual Track I/O Connector is shown
in Table 2-2.
Table 2-1. I/O Connector for Single Track, 8 Pin
Pin Number Color Signal
Connector for Single Track, 8 Pin 1 Brown GND
JAE IL-Y-8S-S15C3 2 Gray STROBE
1.5mm Contact Spacing 3 White DATA
4 Blue CARD PRESENT
5 NC
6 NC
7 NC
8 Red V
CC
Note: V
CC
= 2.4 to 5.5 VDC
Table 2-2. I/O Connector for Dual Track, 8 Pin
Pin Number Color Signal
Connector for Dual Track, 8 Pin 1 Brown GND
JAE IL-Y-8S-S15C3 2 Gray STROBE (Tk 2)
1.5mm Contact Spacing 3 White DATA (TK 2)
Mates to JAE Headers: 4 Blue CARD PRESENT (Tk2)
Straight Pin Header: 5 Yellow *STROBE (TK 1)
IL-Y-8P-S15T2-EF 6 Orange *DATA (TK 1)
Right Angle Pin Header: 7 Green *CARD PRESENT (TK 1)
IL-Y- 8P-S15L2-EF 8 Red V
CC
* Track 1 will be designated Track 3 in P/N 21044002.
Note:
V
CC
= 2.4 to 5.5 VDC
