Swipe Readers With 3-Track SPI IntelliHead
2
SPECIFICATIONS
The specifications are listed in Table 1-2 and in the appendices where noted.
Table 1-2. Specifications
STANDARDS
Card Reading ISO and AAMVA*
Flammability Meets UL94V-0
Speed Card speed through the unit may vary from:
3 to 60 in/s (7.6 to 152.4 cm/s)
ELECTRICAL
All specifications below apply for Vin = +4 VDC to +15 VDC over the operational
temperature range of –40
o
C to +70
o
C. See Figure 3-1 for timing diagram.
Reader Idle Current: < 0.9 mA typical at +25
o
C
Card Swipe Current: 9 mA typical at +25
o
C
Reader Idle Current: < 1 mA typical over operational temperature range
Card Swipe Current: 12 mA typical over operational temperature range
SCL Input Signal:
Input High Voltage: 2.0 V min, 5.0 V max
Input Low Voltage: 0.8 V max
SDA and DAV Output
Signals: Output High Voltage: 2.6 V min at I
OH
= - 3 mA
3.2 V min at I
OH
= - 10 uA
2.5 V typ at I
OH
= - 10 mA
Output Low Voltage:
0.6 V max at I
OL
= 8.5 mA
0.1 V max at I
OL
= 10 uA
1.0 V typ at I
OL
= 25 mA
MECHANICAL
Dimensions See appendix relative to product
Connectors See appendix relative to product
Life 1,000,000 passes
ENVIRONMENTAL
Temperature
Operating:
Storage:
-40
o
C to +70
o
C (-40
o
F to +158
o
F)
-40
o
C to +70
o
C (-40
o
F to +158
o
F)
Humidity
Operating:
Storage:
10% to 90% noncondensing
10% to 90% noncondensing
Altitude
Operating:
Storage:
0-10,000 ft. (0-3048m)
0-50,000 ft. (0-15,240m)
* ISO (International Standards Organization) and AAMVA (American Association of Motor
Vehicle Administrators)
