SECTION 1. FEATURES AND SPECIFICATIONS
The Swipe Readers with 3-Track SPI IntelliHead
TM
provide magstripe reading capabilities for
use in retail access control, time and attendance, and other applications.
The Reader chassis provides an industry standard mechanical footprint, along with magstripe
head capabilities, which comply with ISO 7810 and AAMVA standards. The SPI (Serial
Peripheral Interface) is a synchronous serial bus used for communication between the Reader
and the target system.
MODELS
The current configuration is listed in Table 1-1.
Table 1-1. Models
Part Number Description Tracks Cable Length Appendix
21030023 90mm with SPI IntelliHead 1, 2, 3 140mm B
21044006 43mm with SPI IntelliHead 1, 2, 3 90mm B
FEATURES
• SPI bus compatible 3 wire serial interface. Supports SPI Mode A (CPOL = 1, CPHA = 1)
and Mode D (CPOL = 0, CPHA = 0)
• Maximum SPI bus transfer rate of 100 Kbits/Second
• Reads card in both forward and reverse swipe directions
• Reads 1 to 3 tracks of encoded data meeting ISO 7810, 7811 standards
• Reads track 3 data encoded to ISO 4909 or AAMVA (Drivers license/ID Card) standards
• Less than 1 mA in standby mode
