MT-211 RS-232 Swipe Reader, 1 or 2 Tracks
4
SPECIFICATIONS
Table 1-1 lists the specifications for the MT211232, RS-232 Swipe Reader, 2 Track. Figure 1-3
shows the dimensions.
Table 1-1. Specifications
OPERATING
Reference Standards ANSI/ISO/CDL/AAMVA
Power Input 9 Volt, 300 mA DC Adapter (Included), 110 VAC, 60 Hz
Power Consumption 100mA at 9VDC with PINPad; 45mA at 9VDC without PINPad
Recording Method Two-frequency coherent phase (F2F)
Message Format ASCII
Card Speed 3 to 50 IPS at 75 BPI, 3 to 50 IPS at 210 BPI
MTBF Electronics: 30,000 hours. Head: 1,000,000 passes, except for units
with
Track 2 only;
Head: 300,000 for units with Track 2 only
MECHANICAL
Dimensions Length 6 1/2”, Width 1 3/4”, Height 1 5/8”
Weight: Reader 7 oz. Adapter: 11oz.
Cable length 6’ (with interface cable)
Connector 9 pin D female, requires an interface cable.
ENVIRONMENTAL
Temperature
Operating
0
o
C to 55
o
C (32
o
F to 131
o
F)
Storage -30
o
C to 70
o
C (-22
o
F to 158
o
F)
Humidity
Operating 10% to 90% noncondensing
Storage Up to 100% noncondensing
Altitude
Operating 0-10,000 ft. (0-3,048 m.)
Storage 0-50,000 ft. (0-15,240 m.)
