Triple Track ASIC
2
• AGC (Automatic Gain Control) – reads cards from 30% - 200% of International Standards
Organization (ISO) 7811 amplitude standard
• Wide operational temperature range – -40° C to +85°
C
• Wide range of card swipe speeds – from 2.5 to 100 in/s (6.3 to 254 cm/s) for the standard 75 to
210 bits per inch (bpi) data density
1
• RoHS Compliant – “lead (Pb) free” component
CONFIGURATIONS
Part Number Description
21006529 ASIC, Triple Track, F/2F Decode, MLF14, RoHS-compliant, Tube
21006539 ASIC, Triple Track, F/2F Decode, MLF14, RoHS-compliant, Tape and Reel
Note: The 21006529 and 21006539 are equivalent to the now obsolete 21006536 and 21006537
respectively, except the newer parts are RoHS-compliant (“Pb-free”).
1 The actual minimum instantaneous card speed allowed is 4.7cm/s (1.85ips) using zero-jitter 75bpi data; however, there is a
whole card timeout of 1.35s minimum, yielding a whole card average speed lower limit of approximately 6.3cm/s (2.5ips).
