Triple Track ASIC
18
respected when using the stand-alone chip to allow for easy migration to the Shift-Out IntelliHead
products.
The 7-pin connector shown in the PCB layout is Molex part number 53048-0710. The 5-pin Shift-Out
IntelliHead connector shown in the PCB layout is Molex part number 53048-0510. Other connectors may
be used of course, but this 5-pin connector ensures compatibility when using MagTek Shift-Out
IntelliHead assemblies that already include the wiring and connector.
The MLF
TM
-14 is a near-chip-scale package, and requires some care for proper assembly. It is
recommended, but not required, that the relatively large pad on the bottom of the package be grounded.
For details concerning this package vi
A recommended PCB land pattern for the MLF
TM
-14 package is included in this section. MagTek has
successfully used this land pattern in our manufacturing process, but cannot guarantee success in any
situation, as manufacturing processes do vary. The MLF
TM
or similar package is also known as the QFN
(Quad-Flat-No-lead) package.
