>>Adjusting card thickness
The printer is equipped with a manual card thickness adjustment mechanism which can be reached either through the card feeder or
through the inside of the printing unit when the cover is open. The printer accepts cards between 0.25 mm and 1 mm thick. The factory
setting for card thickness is 0.76 mm.
Adjusting card thickness through the feeder cage:
1. Remove the card feeder from the printer as shown.
2. Adjust the thickness of the cards used by moving the lever from right to left to the desired card thickness.
3. Put the feeder back into the printer by pressing on the upper section of the feeder until it clicks.
1 2 3
