10 3
q SPECIFICATIONS
The following table contains information pertaining to the Master-IT USB
KVM switch.
UR-12 UR-14
Number of computers
supported.
2 4
Front panel push
button
2 4
Hot plug-and-play YES YES
Automatic scan
interval
3, 8, 15, 30 seconds
Cable Length (Max)
30M(100ft) for VGA
5M(15ft) for USB
Computer ON -LINE
LED
2 4
Computer selected
LED
2 4
VGA Resolution 1920 X 1440, DDC2B
USB Connectors
USB Type B (PC Ports)
USB Type A (Console & Peripheral Ports)
Monitor connectors HD-DB-15 male
Power Supply (optional)
Part # PW3-05A20
(5V DC 2A)
Polarity = positive on center
Part # PW3-05A20
(5V DC 2A)
Polarity = positive on center
Weight
420 (grams)
14.8 (ounces)
900 (grams)
31.74 (ounces)
H x W x D (mm)(in.)
1.6 x 4.9 x 2.7 (in.)
40 x 124 x 70 (mm.)
1.7x8.7x5.1 (in.)
44x220x130 (mm.)
q PACKAGE CONTENTS
The ConnectPRO  Master-IT USB Series KVM switch is packaged with
the following items depending on the model you have:
UR-12 UR-14
Master-IT USB KVM Switch 1 1
Cables
Premium 2-in-1 USB/VGA Premium 2-in-1 USB/VGA
Part #: PU-06
Power Supply Included Included
Users’ Manual 1 1
q SYSTEM REQUIREMENTS
q CONSOLE
• One VGA, SVGA or Multisync monitor.
• One USB keyboard.
• One USB mouse.
q COMPUTER
Each USB-enabled computer must be connected to the UR-Series
KVM switch by:
• One HDB15 male-to-female VGA cable (ConnectPRO  Part
Number: CMV-201-S6)
•
One USB patch A-B cable with Type A and Type B plug, as
shown in figure 1. (ConnectPRO  Part Number: UC-AB-6)
Figure 1. UC-AB-6 (6 ft. A-to-B USB Cable)
