© Copyright, Alliance Laundry Systems LLC – DO NOT COPY or TRANSMIT

9001910

10

Operation

Control Panel

Figure 3

Summary of Major Features

Table 1

CHM482R

CHM488R

1

Cycle 1

7

Cycle 7

2

Cycle 2

8

Cycle 8

3

Cycle 3

9

Down Edit/Change keypad

4

Cycle 4

10

Up Edit/Change keypad

5

Cycle 5

11

Start keypad

6

Cycle 6

12

Display

CHM482R

WASH

ADD

BLEACH

RINSE

SPIN

DOOR

NORMAL

NORMAL

QUICK

AS

QUICK WASH

HEAVY SOIL

DELICATE

RM RESS

PERM PRESS

HOT

WARM

HOT

HOT

WARM

COLD

WARM

COLD

START

PE

P

W

H

1

5

6

7

8

4

2

10

3

9

DOMESTIC MODELS

60C

60C

40C

40C

95C

95C

<

<

30C

CHM488R

1

5

6

7

8

4

11

2

3

9

INTERNATIONAL MODELS

12

11

10

12

LED for Machine Functions

LED lights inform operator which machine function is active. DOOR LED lights to
inform operator that the door can be opened or should be closed. The circle LED is
unavailable.

Main LED display

4 digit LED display counts down vend amount and cycle time.

Cycle selection keypads

Eight (8) cycle select keypads with LED indicator to show selected cycle. LED lights
will flash to prompt user to press a keypad.

START keypad

Press to start a cycle after payment is made. LED light will flash to prompt user to press
keypad.

Payment Methods

Coin – Single denomination coin drop meter, prepped for after market coin drop

Fill Temperatures

Cold, Hot, Warm

Supplies

Three (3) – Supply 1 (Compartment A), 2 (Compartment B), and 3 (Compartment C)

Agitation Types

Normal or Gentle

Drain Options

Normally open gravity drain

Automatic Unlock after Power
Failure During Cycle

Standard
