4
H
ARDWARE
I
NSTALLATION
G
UIDE
2.1 S ETTING U P
1.
Place the case upright on a flat, stable
surface with the rear of the case facing
you.
2. Remove the thumbscrews from the right
side panel. Grip the panel at the top and
bottom and slide it toward you to open
the case.
3. Remove the screws from the left side
panel. Grip the panel at the top and
bottom and slide it toward you to
remove the left side panel.
Note: Do not use your fingernails to pry or lift
the panels.
2.2 P OWER S UPPLY I NSTALLATION
1. Between the two chambers there is a plastic structure that lets
you run the cables to the upper and lower chambers. It is a
two-piece structure – one large and one small. Both pieces can
slide back and forth to adjust the openings.
2. Loosen the two thumbscrews holding the plastic structure.
Slide the large piece all the way to the rear of the case to fully
extend the opening. Take any cables that will not be routed
through the cable management chamber and carefully guide
them through the openings to the upper chamber.
3. Fasten the power supply to the back of the case with the
screws provided.
4. Slide the small plastic piece to the rear of the case to fully
extend the other opening.
6. Slide both the large and small plastic pieces all the way to the
front of the case to close the openings when finished with the
hard drive installation.
7. Tighten the two thumbscrews on the plastic structure.
