6
ORIENTATION
Channel selector
Rotate to change the operating channel.
• To change the operating frequency or QT/DQT settings of a
channel, refer to “CHANNEL SETUP MODE” {p.11}.
• If enabled by your dealer, setting the Channel selector to
the “S” position begins Scan. Refer to Scan for details on
how Scan operates. {p.17}
LED indicator
Refer to the LED indicator status. {p.7}
Power switch/ Volume control
Turn clockwise to switch the transceiver ON. To switch the
transceiver OFF, turn counterclockwise until a click sounds.
Rotate to adjust the volume level.
PTT (Push to Talk) switch
Press and hold, then speak into the microphone to transmit.
Antenna
Battery
pack
