11
3
6
Appears when the Automatic Simplex Check (ASC)
function is activated {page 26}.
7
Appears when the Priority Scan function is activated
{page 44}.
8
Appears when the Weather Alert function is activated
{page 36}. (K market models only.)
9
Appears when narrow FM Mode is selected {page 60}.
10
Displays the frequencies, Menu settings, Memory name
and other information.
11
Displays the Menu No., Memory Channel number, and
status {pages 18, 29}.
12
Appears when the displayed Memory Channel has data
{page 29}.
13
Appears when the Key Lock function is ON {page 58}.
14
Appears when the Memory Channel Lockout function is
ON {page 44}.
15
Shows the strength of transmitted {page 15} and received
{page 54} signals.
indicates the squelch is open and the frequency
is “busy”. It also appears when the squelch is set to
minimum {page 14}. If using CTCSS or DCS, it indicates
the squelch is open due to a received signal that contains
the same CTCSS tone or DCS code that is set in your
transceiver.
acts as an S-meter while
receiving and an RF power meter while transmitting.
indicates the transceiver is transmitting.
16
Appears when the function key is pressed.
17
H appears when high power transmission is selected and
L appears when low power is selected {page 15}.
(“M” is not used on this transceiver.)
