Operation
KDAR Company
Operational Controls
The PL-25 Plasma Cutter has the following controls:
 On/Off Power Switch
 Output Current Control
 Purge Button
 Air Input Regulator
Design Features
 Compact and Portable Design
 115 Volts 15 or 20 Amps
 12—25 Amp variable cut settings
 Weighs only 48 Lbs
 Cuts 3/4” mild steel, 1/2” stainless steel and
3/8” aluminum
 9.5 foot torch assembly
 15 foot ground connector
 6 foot power cord
 Immediate pilot arc.
 Purge button
 Built in pressure regulator with standard “M”
quick connect fitting
 On-Off switch with LED power indicator
 LED warning lights for thermal and pressure in-
dicators
 Fan cooled for long life
 No pre-heat
 No distortion of metal
 Clean cuts
 Removes spot welds easily
 Severance cuts to 7/8” with pre-heat
9
Cutting Speeds
Cutting speeds vary greatly and depend on a number of factors. These include, but are not limited to:
 Material Type
 Material Thickness
 Power Setting Selected
 Drag or Offset Cutting
 Temperature
 Humidity
Drag cutting vs. offset cutting (holding the tip approximately 1/16 of an inch off of the material) is a user
preference decision. However, drag cutting requires slower cutting speeds and will wear out tips faster then
offset cutting.
