Electrix iLas User Manual
Page 2
6.125”
FINISHED CEILING PLANE
WALL MOUNT EXTRUSION OR 12”
ADJUSTABLE FILL KITS MAY REQUIRE
FIELD TRIMMING. PLEASE VIEW ALL
DIMENSIONS PRIOR TO INSTALLATION.
USE SUPPLIED LINKING BARS TO CONNECT & ALIGN WALL MOUNT
EXTRUSIONS END TO END.
PLEASE NOTE:
ENGAGE FRAMING
TIGHTEN LINKING BAR
TILT
1
2
PRE-INSTALLATION
FRAMING INSTALLATION
FASTEN WALL MOUNT
EXTRUSION TO VERTICAL
STUDS
