Dake Model Johnson J Saws - Manual (Page 23)

6/02
23
ITEM PART NO. DESCRIPTION QTY
10530-10 Hydraulic Assembly (Includes Control Valve Assembly) 1
10530-09 Cylinder Assembly (Only) 1
1 10031-00 Cylinder Base 1
2 10203-03 Fiber Seal 2
3 10205-02 Tie Rod 3
4 5129-00 Spring 1
4A 5116-00 Spring – R Style included in repair kit. 1
5 17817 3/8 inch Ball 1
6 10204-02 Piston Rod 1
7 10033-00 Head Stop Spring 1
8 5030-10 Cylinder Head 1
9 10115-02 Head Seal (O-Ring) – New Models 1
9A 10115-03 Older Models Garlock Shaft Seal (1/2” ID x 7/8” OD x 1/8” Thick) 1
9B 13080-03 Older Models Garlock Shaft Seal (1/2” ID x .801” OD x 1/8” Thick) 1
10 10013-00 Yoke 1
11 43905 10-24 Nut 3
12 71357 Elbow (Includes furrow and nut) 2
13 10203-02 Cylinder Body 1
14 5119-00 Piston 1
15 5120-00 Piston Nut 1
16 5130-00 Leather Cup 1
10530-08 Control Valve Assembly 1
17 40600-00 Straight Fitting 2
18 1738 Nipple 1/4 x 2-1/2 1
19 70466 Reducer 3/8 x ¼ 1
20 588 3/8 Pipe Plug 1
21 1115 Tee ¼ 1
22 70465 Coupler 1/4 x 1/8 2
23 5131-00 Valve 1
24 44143 90 ° St. Elbow 1
25 1329 1/8 Close Nipple 2
26 10030-00 Face Plate 1
27 13018-14 Knob 1
28 44349 8 x 32 Screw 4
29 40515-00 5/16 Tubing 7 ft. 1
30 40515-00 5/16 Tubing 8 ft. 1
31 5032-00
Oilier (Not Shown) *Note: Items 18-21 are not needed when saw is
equipped with oilier
1
714717
Hydraulic Cylinder Repair Kit (Includes Items 2, 4, 4A, 5, 9, 9A,
9B & 16)
10530-01 Rod & Piston Assembly (Includes Items 4,5,6,14,15 & 16)
