Page 19
6/02
19
MACHINE ASSEMBLY, Front View
ITEM
PART NO.
DESCRIPTION
QTY
1
10002-01
Front Frame
1
2
10003-01
Rear Frame
1
3
10001-00
Bed
1
4
10066-00
Pivot Bar
1
5
13010-08
Shaft Locking Collar
2
6
10004-02
Right Leg
1
7
10005-02
Left Leg
1
8
10070-00
Balance Spring - includes carriage bolt and nut
1
9
10100-01
Spring Perch
1
10
10101-00
Outboard Bearing Casting – (uses 3/8” bolt – lockwasher - nut)
1
11
5527-00
Stock Stop Assembly
1
11A
5027-00
Holder Casting
1
11B
5213-00
Rod
1
11C
5028-00
Spring
1
11D
5200-00
Handle
1
12
5027-01
Stock Stop Mounting Bar
1
13
10006-01
Tip-off Block
1
14
10269-00A
Coolant Drawer Pan
1
15
300405A
Left Hand Blade Guard
1
16
300404A
Right Hand Blade Guard
1
17
18
10268-07A
Left Leg Pan
1
19
10268-05A
Right Leg Pan
1
20
10093-00
Frame Handle
1
21
10229-00
Brush holder Guard
1
22
72295
Dake/Johnson Name Plate
1
23
71541
Submersible Coolant Pump – Electric 110 volt
1
PARTS NOT ILLUSTRATED
PART NO.
DESCRIPTION
QTY
10079-05
Motor, 230/460 volt, 60 Hz, 3 phase – 1 H.P.
1
10079-07
Motor, 110/230 volt, 60 Hz, 1 phase – 1 H.P.
1
10042-10
Motor Pulley – 5/8” Bore
1
10077-10
Drive Belt
1
10223-10A
Pulley Guard
1
5107-00
Motor Hanger Base
1
5106-02
Frame Hanger Motor Base
1
5106-03
Motor Mounting Pin
1
300403A
Frame Covers (Left and Right Hand Sides)
2
300804
Knob for Frame cover 300403A
4
10230-10A
Rear Frame Blade Guard
1
10271-00A
Drive Wheel Drip Pan
1
10287-00
Strap, Wheel Pan
1
10286-00
Bar, Wheel Pan
1
70295
Thumb Screw – Drive Wheel Drip Pan
2
10209-01
Spring Bracket Top
1
10126-13A
Lower Left Front Cover
1
10091-10
Frame Rest
1
300407A
Drive Wheel Cover
1
300408A
Idle Wheel Cover
1
300409A
Drive & Idle Wheel Spoke Guards
2
300246
Wire Ties
12
MACHINE ASSEMBLY, Top View
