FORCE 50 DA HYDRAULIC PRESS
PARTS LIST
Item # Qty Description Part # Item # Qty. Description Part #
1 1 Frame 50 Ton 87137 20 1 Nose Piece 87138
2 4 Hex Cap Screw 1/2"-13x3 1/4" lg 43356 21 4 Lock Washer 5/8" 43648
3 4 Channel Washer 1/2" 43657 22 4 Hex Nut 5/8"x11 43917
4 1 Work head Assembly 716547 23 1 Hydraulic Power Unit 301856
5 4 Lock Washer 1/2" 43647 24 4
Hex Cap Screw 5/16"-
18 NCx1/2"lg 43313
6 4 Hex Nut 1/2"-13 43916 25 4 Lock Washer 5/16" 43644
7 2 Base Angle 566 26 4 Hex Nut 5/16"-18 43911
8 4
Hex Cap Screw 1/2"-13NC X 1
1/2" lg 43349 27 1 Label 301879
9 6 Table Pin 569 28 1 Label 84487
10 6 Retaining Ring 43980 29 1 Label 84399
11 2 Table Channel 706945 30 1 Label 300168
12 4 Lock Washer 1/2" 43647 31 1 Label 76462
13 4 Hex Nut 1/2"-13 43916 32 1 Label 84395
14 4 Table Bolts 79983 33 1 Name Plate 301856
15 4 Table Spacer 86488 34 1 Label 76936
16 2 Shackle 301884 35 2 Table Plate 702
17 2 Chain 301881 36 2 V-Block 336
18 4 Spring Snap 301882 37 1 Dake Name Plate 81002
19 2 Eye Bolt 301880
