Steffy Wood Products Toddler Storage with Mirror Back - Manual

PARTS LIST
DESCRIPTION PART NUMBER QTY
HEX KEY 7201 1
CONNECTOR 7205 8
CONNECTING SCREW 7206 8
CONNECTING BOLT 7213 12
BUMPER 7217 1
1" LONG SCREW 7242 1
SCREW DRIVER 7271 1
MIRROR 7283 1
LEFT SIDE 80203L 1
RIGHT SIDE 80203R 1
TOP PANEL 80204 1
BOTTOM PANEL 80205 1
TOP STRIP 80206 2
DIVIDER 80207 1
BACK PANEL 80208 1
701 West Mill Street
Angola, Indiana 46703
CAUTION: CHOKING HAZARD
Adult assembly required due to the
presence of small parts and sharp edges.
Questions?
Phone: 1-800-656-8586
Email: [email protected]
Steffy
Wood Products, Inc.
Item #SWP7177
Toddler Discovery Center
TOP STRIP
80206
TOP PANEL
80204
LEFT SIDE
80203L
RIGHT SIDE
80203R
BOTTOM PANEL
80205
DIVIDER
80207
CONNECTOR
CONNECTING BOLT
1" LONG SCREW
BUMPER
LEFT SIDE
CONNECTING SCREW
TOP PANEL
1
Using the supplied screwdriver, attach the
connecting screws to the side panels and top
as shown. DO NOT USE A POWER TOOL
TO ATTACH THESE CONNECTING
SCREWS!!
Insert the plastic connectors into the large
holes in the top strips. Be sure the flat edge
of the connector aligns with the flat edge of
the strips.
CONNECTOR
TOP STRIP
HEX KEY
CONNECTING SCREW
SCREW DRIVER
