Steffy Wood Products 20-Tray Storage Cabinet - Manual

PARTS LIST
DESCRIPTION PART NUMBER QTY
Hex Key 7201 1
CONNECTING BOLT 7213 12
BUMPER 7217 1
1" LONG SCREW 7242 1
SIDE PANEL 80001L 1
SIDE PANEL 80001R 1
DIVIDER 80005 4
BACK PANEL 80006 2
TOP PANEL 80007 1
CENTER SHELF 80008 1
SHELF 80009 2
BOTTOM PANEL 80025 1
701 West Mill Street
Angola, Indiana 46703
CAUTION: CHOKING HAZARD
Adult assembly required due to the
presence of small parts and sharp edges.
Questions?
Phone: 1-800-656-8586
Email: [email protected]
Steffy
Wood Products, Inc.
Item #SWP7153
20-Cubbie Storage
BUMPER
7217
CONNECTING BOLT
7213
1" LONG SCREW
7242
HEX KEY
7201
1
Attach one side panel to the top, shelf
and bottom panels using six connecting
bolts and the hex wrench. Be sure the
slots for the back panels are aligned in
each panel.
SIDE PANEL
CONNECTING BOLT
BOTTOM PANEL
CENTER SHELF
TOP PANEL
TOP PANEL
80007
SIDE PANEL
80001R
BOTTOM PANEL
80025
SHELF
80009
SIDE PANEL
80001L
SIDE PANEL
80001L
Slots for back panels
