Steffy Wood Products Computer Table - Manual (Page 2)

2
Attach the right side to the top, rear and
center panels using the connector bolts
and hex key.
3
Attach the casters with brake to the
front of the side panels. Slide the
metal "U" bracket onto the bottom of
the side. Be sure the large hole in
the metal bracket is facing out.
Secure the caster by inserting black
machine screw through the large hole
on the outside metal bracket and
tighten with a screwdriver.
Attach the two remaining casters to
the rear of the side panels using the
same procedure .
MACHINE SCREW
4
Insert two shelf pins into the holes in each side panel
at the desired height. Place the keyboard shelf onto
the shelf pins. After the keyboard shelf is in place,
rotate the plastic turn buttons on the bottom of the
keyboard shelf until they are over the shelf pins.
PLASTIC TURN BUTTON
UNDER SIDE OF
KEYBOARD SHELF
Shelf Pin
Check all bolts and screws periodically
to make sure they are tight!!
SIDE PANEL
REAR PANEL
TOP PANEL
CENTER PANEL
SIDE PANEL
CASTER - WITH BRAKE
CASTER - WITH BRAKE
CONNECTING BOLT
Shelf Pin
