PLASTIC DIVIDER
BACK PANEL
4
Attach the remaining side to the top, shelf and
bottom panels. Be sure the shelves and back panels
are in the slots in the side panels.
5
(refer to sketch at right)
Attach the ceiling hooks to the shelf using the 5/8"
long posts and flat head screws. Insert the posts
through the top holes in the shelf, hold the hook in
place over the holes at the bottom of the shelf and
secure with the flat head screws.
3
(refer to sketch below and at right)
There are 2 WIDE back panels and 3 NARROW
back panels. Slide a WIDE back panel into the
slots in the shelf, bottom and side panel. Be sure
the panel is completely in the slot in the side
panel.
Slide a plastic divider onto the edge of the WIDE
back panel, then slide a NARROW back panel into
the slots in the shelf and bottom panels and into
the open edge of the plastic divider.
Repeat this process for the remaining lower back
panels.
Slide the upper back panel into the slots in the
top, shelf and side panel.
CHECK ALL BOLTS AND
SCREWS PERIODICALLY TO
MAKE SURE THEY ARE TIGHT!
RIGHT SIDE PANEL
WIDE BACK PANEL
UPPER BACK PANEL
WIDE BACK PANEL
NARROW BACK PANEL
BOTTOM PANEL
LEFT SIDE PANEL
TOP PANEL
WIDE BACK PANEL
PLASTIC DIVIDER
UPPER SHELF
WARNING !!
Serious or fatal crushing injuries can occur from
furniture tip-over. To help prevent tip-over:
Place heaviest items on bottom of cabinet.
Never allow children to climb or hang on doors or shelves.
Use of tip-over restraints may only reduce, but not eliminate,
the risk of tip-over.
6
Furniture tipping restraint hardware is included in with the
hardware package for this unit. Follow the installation
instructions printed on the restraint hardware bag.
CEILING HOOK
1/2" FLAT HEAD SCREW
1/2" LONG POST
