Steffy Wood Products Two Station Art Center - Manual (Page 2)

2
Attach the two top strips as shown using
1-1/2" long screws provided and a screwdriver.
Be sure the rounded, smooth edge is up.
1-1/2" LONG SCREW
TOP STRIP
3
Open the pre-assembled easel frame. Be sure the
arms on each side are locked into position.
Insert the 3/4" long bolts through the holes in the
easel panels and blue easel trays, Secure the tray
with the blue wing nuts.
Lift the easel panel assembly onto the base cabinet.
Be sure it rests on the top panel between the sides
and top strips. Four easel clips are provided to hold
the paper to the easel board.
EASEL TRAY
BLUE WING NUT
CHECK ALL BOLTS PERIODICALLY
TO MAKE SURE THEY ARE TIGHT!
EASEL PANEL ASSEMBLY
EASEL PANEL ASSEMBLY
TOP STRIP
SIDE PANEL
TOP STRIP
SIDE PANEL
ARM
