4
4868C–DECT–05/06
ATR7040
Electrostatic sensitive device.
Observe precautions for handling.
3. Absolute Maximum Ratings
Stresses beyond those listed under “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress rating
only and functional operation of the device at these or any other conditions beyond those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended periods may affect device reliability.
Parameters Symbol Value Unit
Supply voltage V
CC
5 V
Supply current I
cc
400 mA
Junction temperature T
j
150 °C
Storage temperature T
Stg
–40 to +125 °C
Input RF power P
in
10 dBm
Control voltage V
ctl
2.5 V
Note: The part may not survive all maximums applied simultaneously.
4. Thermal Resistance
Parameters Symbol Value Unit
Junction ambient package QFN16, 3 × 3,
slug soldered on PCB
R
thJA
40 K/W
5. Operating Range
Parameters Symbol Value Unit
Supply voltage V
CC
2.7 to 3.8 V
Operating frequency range f
in
5100 to 5900 MHz
Ambient temperature range T
amb
–25 to +75 °C
