VariZoom VZM7 - Manual

VZ-M7 HDMI Field Monitor – 7” Class HD LCD
The VZ-M7 HDMI monitor provides sharp, accurate images for improved framing and focus assist on any camera equipped with an
HDMI output. Utilizing top-quality Grade A+ LCD panels and image processing, the M7 offers picture quality and a feature set normally
found only on more expensive monitors. Included with the basic M7 kit: monitor, HDMI cable and AC power adapter. A number of
optional accessories designed specifically for the M7 are available through VariZoom.
Warnings:
 Do not use the monitor in extremely hot and humid environments.
 Never open the monitor case or attempt repair
– this will void the warranty.
 Use only a soft cloth and no chemicals to clean the LCD screen.
 DO NOT USE THE AC ADAPTER AND BATTERY AT THE SAME TIME. UNPLUG AC ADAPTER WHEN USING BATTERY
POWER.
 The monitor can only handle 6.5-36VDC with CORRECT polarity.
 Do not plug anything into the micro USB port on the underside of the monitor (factory use only).
 Do not pl
ug anything into the “Zoom” port on the monitor other than the optional zoom/peaking trigger remote (NEVER plug a
camera zoom control into this port).
Features:
 Accepts all HD signals up to 1080p
 HDMI In / Out (loop through)
 DSLR Scaling to allow full-screen viewing of image from cameras such as Canon 5D
 Auto Aspect Ratio Detection
 Monochrome (B&W) mode
 Image Flip for inverted mounting
 Safety Area markers (5 levels), Centerline Marker, 4:3 area markers
 Underscan and Overscan modes
 Color Temperature Presets (D65 and D93 standards), or user-defined through RGB settings
 Brightness, Contrast, Saturation, Sharpness adjustments
 Customizable Menu Options for menu duration, position, text color and language
 Headphone jack and speaker for audio monitoring
