VariZoom VZTC100A - Manual

VZ-TC100A
Aluminum Video Tripod
Features:
• Single-stage, heavy duty legs with adjustable mid-level spreader
• 100mm bowl compatible w/ a wide range of heads, including VZ-
H100 & ZG
• Can be attached to the VZ-D100 or Cinetrac Dolly for tracking
shots
• For use with cameras up to 30Ibs
Assembly:
The lower double-legs slide out and lock
to allow a wide range of height adjustment.
Make sure when packing the tripod that all
legs are locked together using the included
clips to prevent shuffling and possible
damage.
To lock or unlock the legs for height
adjustment, simply pull up the locking clamp
and slide the legs out to the desired length.
Make sure each lock is secured completely to
prevent the leg sections from shifting under the
weight of the camera. The spreader can be
adjusted for a wider or narrower sprawl.
Rubber feet are included to help the tripod grip many
different flat surfaces; the feet are removable for spiking
into soft ground, uneven surfaces, or attachment to dollies
or other devices.
The VZ-TC100A tripod is covered by a one-year warranty (parts/labor). Please retain your receipt for warranty verification.
All returns and repairs must be accompanied by a Return Merchandise Authorization number
Warnings: Do not put more than the recommended weight onto the tripod.
