CDN TM9 - 2-Ev ENt Timer & Clock EN User Manual
Event timer & clock, Features, Battery installation

Features
•
2 channels
•
Dual function
•
Memory
•
Dual progress display
•
Counts up/down in 2 channels simultaneously
•
Extra big digit
•
Clock
•
Loud and long alarm
•
Individual channel sounds
•
Stop and restart
•
Last count recall
•
Counts up after zero
•
ABS plastic
•
Sliding mode switches
•
International time
•
2-way mounting: stand/wall mount
•
Battery and instructions included
Note:
Remove sticker from display before use.
Note:
In the following instructions, names of the control
buttons are shown in CAPS. Function information that appears
on the display is shown in
BOLD CAPS.
Battery Installation
Replace battery when LCD becomes dim or alarm
level declines.
1. Remove battery door in back by pressing tab
and lifting.
2. Install one 1.5V AAA battery observing polarity
shown in compartment.
3. The display will show all segments and a “beep”
will sound.
4. Replace the battery cover until it clicks shut.
Operating Instructions
A. Set Clock
1. Select CLOCK using sliding mode switch on left
side of case.
2. Press the 12HR-24HR/MEMORY button to
switch between 12-hour, AM/PM time, and
24-hour, international time.
3. Select SET using sliding mode switch on back
of case. The digits flash in the upper portion of
the display under
CLOCK.
4. Press the HR, MIN and/or SEC buttons on back
of case to enter the desired time. Press and hold
for fast advance.
5. Select LOCK using sliding mode switch on back
of case to prevent unintended time changes
and resume the clock function. The digits stop
flashing.
B. Count Down
1. Select TIMER 1 or TIMER 2 using sliding mode
switch on left side of case. Both count down
timers appear on the display.
2. Select SET using sliding mode switch on back
of case. The digits flash in the upper portion
of the display under TIMER 1 or TIMER 2
respectively.
3. Press the HR, MIN and/or SEC buttons on back
of case to enter the desired time. Press and hold
for fast advance.
Model: TM9
2-Event Timer & Clock
Counts 10 hours by minutes & seconds
CLOCK
TIMER
1 & 2
TIMER 1 TIMER 2
12
HR
24H
R
M E MORY
C LEAR
START/STOP
TIMER 1
TIMER 2
HR
MIN
SET
LOCK
SEC
MADE IN CHINA
Component Design
Northwest, Inc.
Portland, OR
Model TM9
