CDN TM30 - Direct ENtry 2-Alarm Timer EN - Manual

Features
• Counts up & down
• Big digit
• Direct entry
• Loud and long alarm
• Audio/vibrate alarm
• Stop and restart
• Last count recall
• Counts up after zero
• Brushed stainless steel finish
• ABS plastic
• Sliding mode switch
• 4-way mounting:
pocket clip/magnet/stand/loop
• Battery and instructions included
Note: Remove sticker from display before use.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that appears
on the display is shown in BOLD CAPS.
Battery Installation
Replace battery when LCD becomes dim or alarm
level declines.
1. Remove battery door in back by sliding in
direction of arrow.
2. Install 1.5V AAA battery observing polarity
shown in compartment.
3. The display will show all segments and a “beep”
will sound.
4. Replace battery door.
Operating Instructions
A. Set Alarm
1. Slide switch on the back to BEEP or VIBRATE
to select alarm mode.
B. Count Down
1. Enter the time to be counted on the 1 – 0
keypad. For example, to count 3 minutes
exactly, enter 3 0 0 for three minutes,
zero seconds. To count 9 hours, 45 minutes
and 30 seconds, enter 9 4 5 3 0.
2. Press START/STOP to start the count down.
Press START/STOP button to interrupt the
count. Press START/STOP button again to
resume the count.
3. To clear the count before reaching zero,
stop the count by pressing START/STOP.
Then press the CLEAR button.
Note: The count must first be stopped to prevent
accidental clearing of the display.
4. On reaching zero the alarm will sound for one
minute, the display will flash and will start
to count up to indicate the overtime since
reaching zero. The maximum overtime is
10 hours.
5. Press START/STOP to stop the alarm and the
count up. The last count is recalled.
6. Press CLEAR to reset to 0:00
00
.
C. Count Up
1. When the timer is stopped, press CLEAR to
reset to 0:00
00
.
2. Press START/STOP to begin the count up to a
maximum of 10 hours.
3. Press START/STOP to interrupt the count.
Press START/STOP again to resume the count.
4. To clear the display, press START/STOP to
stop the count. Then, press CLEAR to reset the
display to 0:00
00
.
Model: TM30
Direct Entry
2-Alarm Timer
Counts 10 hours by minutes & seconds
1
START/STOP
6
2
7 3
8 4
9 5
0
CLEAR
Component Design Northwest, Inc.
Portland, OR Model TM30
VIBRATE
BEEP
