Chapter 1 - Getting Started

1-3

1.2.2

Rear Panel

Figure 1-2 shows the system unit rear panel.

1. Fan

9. Parallel Port

2. System Main Power Switch

10. Monitor/VGA Port

3. Voltage Selector

11. Audio-out Port

4. System Power Socket

12. Audio-in Port

5. USB Ports

13. Game/MIDI Port

6. PS/2 Mouse Port

14. Microphone-in Port

7. PS/2 Keyboard Port

15. Add-on Card Brackets

8. Serial Port

Figure 1-2 Rear Panel
