53 U104613-03
Read all instructions before installing or using this appliance.
Installation Instructions
Save these instructions for future reference.
Technical Data
This range is supplied set for Natural gas.
A conversion kit from NG to LP gas is included.
INSTALLER: Please leave these instructions with the User.
DATA BADGE LOCATION: Under the Main oven. Remove the plinth by pulling forward (it is held in place
by magnetic catches) and pull forward on the sheet metal tag under the center of the oven to swing out the
badge plate.
Country of Destination: USA/Canada
Gas Electric
Natural Gas 4.0” W.C (10 mbar) 240V 60Hz
Propane 10.0” W.C ( 25 mbar)
(See appliance data badge for test pressures)
Dimensions
Overall height (splash not fitted) minimum 35 3 /
8
” (89.8 cm) maximum 36 7 /
16
” ( 92.5 cm)
Overall width 35 1 /
2
” (90cm) See ‘Positioning the Range’
Overall depth with spacer 28 3 /
4
” (73cm)
Space for fixing See ‘Positioning the Range’
Minimum space above cooktop 30” (76cm)
Connections
Gas : Electric:
1 /
2
” NPT at rear right-hand side
240 V 60 Hz
