Operating and installation instructions
FABA
®
-Plus / FABA
®
-Supra / FABA
®
-LA
4.4 Parts
4.5 Technical data - remarks
for
- Principal dimensions
- Pressure-temperature-ratings
- Valves with butt weld ends, etc. refer to datasheet.
4.6 Marking
Details of the CE-marking on the valve:
CE-marking
0525 Notified body
Manufacturer Address of manufacturer:
refer to item 11.0 Warranty / Guarantee
Typ Type
Bj. Year of manufacture
According to the Pressure Equipment Directive table 6, annex II, valves without safety
function are only allowed to bear the CE-marking DN32 onwards.
Pos. Designation
1
Body
1.2 Seat
2 Bonnet
3 Plug
4 Stem unit
4.1 Bellows seal
4.1.2 Clamping flange
4.2 Stem
5 Handwheel
6 Packing ring
7 Hexagon screw / Stud
8 Hexagon nut
9 Gasket
10 Spring-type straight pin
11 Packing follower
12 Screw joint
13 Safety washer
14 Grooved pin / Spring-type straight pin
15 Threaded bush
16 Washer
17 Shim ring
18 Retaining ring
19 Guard cap
22 Stem ring
23 Safety plate
24 Screw joint
25 Guide bush
26 Bushing
27 Stuffing box glands
28 Flap type screw
29 Locking pin
30 Washer
31 Hexagon nut
32 Flange cover
41 Washer
42 Hexagon nut
43 Hexagon nut
44 Stem
45 Coupling
46 Cylinder screw
Pos. Designation
