ASSEMBLY
Your comes fully assembled. Simply place it
on top of a sturdy work table and you are ready to work.
PUNCHING
1. Move (align) Side Margin Guide to proper sheet & cover size.
2. Insert sheets and pull handle forward to punch.
3. Return Punch handle to its upright position.
4. Repeat steps two and three as needed.
TIPS:
a) Maximum single punching: 10 sheets of 20 lbs. paper
b) Comfortable single punching: 8-10 sheets of 20 lbs. paper.
5
2. 3.
1.
C O I L I N S E R T I N G ( B I N D I N G )
1. Insert coil into first three or four holes. See picture 1
2. Place your punched document onto Coil Inserting Table and finish inserting coil by sliding
hand. See picture 2
3 Use a set of pliers to cut-off any excess coil and bend. Make sure you bend-in both coil ends.
This procedure will avoid document from unbinding itself. See picture 3
See Picture 1.
See Picture 2.
See Picture 3.
