Aspire Digital 7520 - Manual (Page 41)

Chapter 1 35
Bluetooth
Foxconn Bluetooth ® 2.0+EDR
Wireless LAN Foxconn Atheros XB63 minicard b/g
Fox BRM 4311 Minicard BG
PCMCIA TI PCI 7412
Audio Realtek ALC268
Keyboard
Item Specification
Keyboard controller KBC1122
Total number of keypads 88-/89-key
Windows logo key Yes
Internal & external keyboard work
simultaneously Plug USB keyboard to the USB port directly: Yes
Battery
Item Specification
Vendor & model name BATTERY PANASONIC LI-ION
6CELLS
BATTERY SANYO LI-ION 6CELLS
BATTERY SIMPLO LI-ION 6CELLS
BATTERY SONY LI-ION 6CELLS
BATTERY PANASONIC LI-ION
8CELLS
BATTERY SANYO LI-ION 8CELLS
BATTERY SIMPLO LI-ION 8CELLS
BATTERY SONY LI-ION 8CELLS
Battery Type Li-ion
Pack capacity 4000 mAH or 4800 mAH
Number of battery cell 6 cell or 8cell
Package configuration 9 cells in series, 2 series in parallel
Normal voltage 14.8V
Charge voltage 16.8+-0.2v
LCD 17” inch
Item Specification
Vendor & model name LCD 17 WXGA
GLARE AUO
B170PW03 V4
200nits 16ms LCD 17 WXGA
GLARE CMO
N170C2-L02
10ms 200nits LCD 17 WXGA
GLARE LPL
LP171WP4-
TLB1 16ms
200nits LCD 17 WXGA
GLARE
SAMSUNG
LTN170X2-L02-
H 16ms 200nits
PMMA
Screen Diagonal (mm) 17 inches 17 inches 17 inches 17 inches
Active Area (mm) 304.1x228.1 304.1x228.1 304.1x228.1
Display resolution (pixels) 1440x900
WXGA+ 1440x900
WXGA+ 1440x900
WXGA+ 1440x900
WXGA+
Pixel Pitch 0.297x0.297 0.099x0.297 0.297x0.297
Pixel Arrangement R.G.B. Vertical
Stripe R.G.B. Vertical
Stripe R.G.B. Vertical
Stripe R.G.B. Vertical
Stripe
System Board Major Chips
Item Controller
