Bars from
Ø120 mm - Ø180 mm Bars from Ø200 mm
Right or left style. Contact your salesman to
order new front if you have to change the cut
direction.
Easy to change front.
Loosen the
screws
Lifting
Standard with
hole pattern for
Coromant Capto
clamping unit
C6-R/LC2090 -42060
Right or left style, Turn the bar or the front 180
degrees.
How to turn the front 180 degrees? Loosen the
front screws and then only turn the front.
Adaptors
With quick change
Shank holder
The bars are packed in solid box. To lift the bar
out from the box straps will be located near the
centre of gravity (Bars from Ø120 mm).
