- 3 -
Contents
1. Unpacking and mounting into a 19" rack
page 3
2. Powering up and selecting timecode SOURCE page 4
3. LTC input mode page 5
4. MTC and USB input modes page 6
5. GEN generator mode page 7
6. DISPLAY modes page 9
7. Setup utility page 11
8. USB drivers page 12
9. Declaration of conformity page 13
10. Specifications page 14
1. Unpacking and mounting into a 19" rack
mif 4 comes with the following accessories:
1 pcs power adapter with country-specific clip
1 pcs USB cable
2 pcs 1U rackmount brackets
1 pcs user manual that you are now reading
The unit is shipped with four small plastic feet mounted underside
with Philips screws.
If you want to rackmount your mif 4, please detach the four plastic
feet first and keep the M3x6mm Philips screws.
Now remove the black countersunk screws on the left and right side
of the unit to assemble the rack mount brackets using the M3x6mm
Philips screws.
