- 14 -
10. Specifications
LTC input: XLR 3-pin female, balanced, pin 1 = GND, 2 = (+), 3 = (-), 10 k Ώ ,
reads forward, reverse and stationary timecode at
5 to 500% of nominal speed (SMPTE 12M).
input level tolerance -30 to +20dBu.
LTC output: XLR 3-pin male, balanced, pin 1 = GND, 2 = (+), 3 = (-).
source 1 k
Ώ , short circuit proof.
outputs nominal forward and stationary timecode (SMPTE 12M).
output level adjustable from 0.. +8dBu (5.5Vpp).
MIDI input: 5-pin DIN connector, MIDI specification 1.0.
MTC quarter frames, MTC full message (time and userbits),
MMC stop, play, defplay, locate, write userbits (field 47)
Rosendahl Sysex.
MIDI output: 5-pin DIN connector, MIDI specification 1.0.
MTC quarter frames, MTC full message,
Rosendahl Sysex.
USB: USB type B, device class compliant MIDI (USB audio).
plug & play with Windows XP or later, MAC OSX.
MTC quarter frames, MTC full message (time and userbits),
MMC stop, play, defplay, locate, write usebits (field 47).
Rosendahl Sysex.
Sync input: BNC, internally terminated, 300mV sync, +/- 300mV tri-level.
auto detection of the following video standards:
576i47.95, 576i48, 576i50(PAL), 480i59.94(NTSC), 480i60,
720p50, 720p59,94, 720p60,
1080i47.95, 1080i48, 1080i50, 1080i59.94, 1080i60,
1080p23.98, 1080p24, 1080p25, 1080p29.97, 1080p30,
1080p50, 1080p59.94, 1080p60.
Power: USB bus powered, 5V DC, < 300mA via host computer
or stand alone operation with separate external power adapter.
Dimensions: 0.56" 7-segment LED display.
44mm (H =1U) x 168mm (W) x 110mm (D without BNC connector),
1U rackmout brackets are included, weight 0.6 kg.
