22
-EN
Connections
* 1 When Subwoofer is set to OFF: Output is from Rear speakers.
When Subwoofer is set to ON: Output is from Subwoofer.
* 2 When Subwoofer is set to OFF: Output is from Front speakers.
When Subwoofer is set to ON: Output is from Subwoofer.
For details on how to set the Subwoofer to ON/OFF, see “Subwoofer On and Off” on page 16.
,
,
+
-
(
&
%
$
#
"
!
9
7
6
5
3
4
2
)
~
8
1
Antenna
To power antenna
To amplifier or equalizer
Battery
Front right
Rear right
Speakers
Rear left
Front left
Speakers
Amplifier
Amplifier
Front Left
Front Right
(CDE-9845 only)
Gray
Gray/
Black
Violet
Violet/
Black
Green
Green/
Black
White
White/
Black
To the instrument cluster
illumination lead
CDE-9845:
Rear or Subwoofers
∗
1
CDE-9843/CDE-9841:
Front or Subwoofers
∗ 2
Ignition Key
SPEAKER
LEFT
FRONT
SPEAKER
LEFT
REAR
SPEAKER
RIGHT
REAR
SPEAKER
RIGHT
FRONT
Red
IGNITION
Yellow
BATTERY
Black
GND
Blue
POWER ANT
Blue/White
REMOTE
TURN-ON
Orange
ILLUMINATION
(CDE-9845/CDE-9843 only)
(), -: CDE-9845 only)
