8 PCM-3420 User's Manual
Jumpers and Connectors
Connectors on the board link it to SCSI devices and other PC/104
modules. In addition, the board has a number of jumpers that allow
you to configure the SCSI application to suit your systems.
The table below lists the function of each board jumpers and connec-
tors:
Jumpers
Label Function
JP1 LED Indicator Location
JP2 Termination Select
JP3 Set DMA Channel Select
JP4 Set IRQ Channel Select
JP5 Set PCM-3420 SCSI ID, IRQ, DMA, Parity
Checking
JP6 Set PCM-3420 Operation Mode
JP7 Set Port Address
JP8 Set PCM-3420 BIOS Address
JP9 Set PCM-3420 BIOS Address
JP10 Set PCM-3420 BIOS Function
Connectors
Label Function
J1 PC/104 ISA-bus expansion
J2 PC/104 ISA-bus expansion
