8
Multiplex Lists stations in groups according to their multiplex. Multiplexes, sometimes
called ensembles, are groups of stations owned and broadcast by a single
operator.
Trim stn. list Removes inactive stations from the station list.
→ presets
Available only when Fav station order (above) has been selected. Transfers
your favourite stations to the eight presets.
Autotune UK
Scans all UK frequencies for DAB stations and adds any new ones to the station list.
Autotune full
Scans the full range of digital frequencies in Band III. This option is for use outside the UK
where other Band III stations may be available.
Manual tune
Shows signal level which you can use to find the best position for your radio and aerial.
1. Use the +/- buttons to scroll through different channels and push Select to choose one
(UK stations are in the range 11B to 12D). You see a signal level display.
The empty block indicates the minimum required level for reception and the filled blocks
indicate the current level.
2. Move your aerial while watching the display and to try to raise the current level to the
empty block or beyond. Once you have a good signal the display will show the multiplex
name and add the stations to the station list.
3. Push the Menu button to exit the tuning aid or +/- and Select buttons to change station.
Note You can display the signal level at any time by pushing the Select button.
Autotune... 12
Autotune UK Band III option
12B 225.64MHz
Manual tune - channel
12B 225.64MHz
Manual tune - low signal
12B BBC DAB
Manual tune - good signal
