described in the next section.
15. (-) PITCH BEND - The (-) pitch bend function
creates a momentary “Slow Down” in the CD’s
pitch speed (Beats per minute - BPM) when the
PITCH (7) function is activated. This functions
allows the beats between two CD’s or any
other music source to match. This is a momen-
tary function. When the
button is depressed
the pitch speed will automatically return to PITCH
SLIDER'S (23) selected pitch. Holding down
this button will give a maximum of -16% pitch.
Be sure to remember that this function is a
momentary pitch adjust-ment, for a more precise
adjustment use the
PITCH SLIDER'S (23) to
match the BPM’s with another playing music
source.
16. (+) PITCH BEND - The (+) pitch bend func-
tion creates a momentary “BUMP” in the CD’s
pitch speed (Beats per minute - BPM) when the
PITCH (7) function is activated. This functions
allows the beats between two CD’s or any other
music source to match. This is a momentary
function. When the button is depressed the pitch
speed will automatically return to
PITCH SLID-
ER'S (23) selected pitch. Holding down this but-
ton will give a maximum of +16% pitch. Be sure
to remember that this function is a momentary
pitch adjustment, for a more precise adjustment
use the
PITCH SLIDER'S (23) to match the
BPM’s with another playing music source.
17. TEMPO LOCK - This button will activate the
Tempo Lock function. This function will allow you
to make adjustment to a track speed using the
pitch controls (7, 15, 16, & 23) without altering a
tracks perceived tonal pitch.
18. SHUTTLE WHEEL - (OUTER RING) This
wheel has two forward and two reverse speed
positions for speed searching through tracks.
The more you turn the wheel in either direction,
the faster you search.
19. JOG WHEEL - (INNER WHEEL) This jog
wheel serves two functions depending on the
current operating mode:
A. The jog wheel will act as a slow frame
GENERAL FUNCTIONS AND CONTROLS - REMOTE UNIT CONT.
search control when the unit is in pause or
cue mode allowing you to set a specific cue
point or find a particular starting point.
B. The inner wheel also works as a momentary
pitch bend during playback. Turning the wheel
clockwise will increase the pitch percentage
up to 16%, and turning the wheel in the
counterclockwise direction will decrease the
pitch percentage up to -16%. The pitch bend
will be determined on how fast you turn the
wheel.
20. TRACK BUTTON - This buttons is
used to select a track. Tapping this button will
back-skip to the previous track, holding down this
button will rapidly back-skip through the tracks
on a CD.
21. TRACK BUTTON - This buttons is
used to select your desired track. Tapping this
button will forward skip to the next track, holding
down this button will rapidly forward skip through
the tracks on your CD.
22. DTA/FX (DATA/EFFECTS) - This button
serves two functions. This button allows you to
change the functions of the effect and cue button
along the top of the
LCD (14) . DATA: The DATA
function will be indicated by small arrow icon in
the upper left hand corner of the LCD (14). When
unit is in DATA mode the effect and cue buttons
along the top of the
LCD (14) may be used as
direct track access buttons. EFFECTS: When the
effect function is engaged (no arrow icon in the
upper left hand corner of the LCD) the buttons
along the top of the
LCD (14) will function as
they are indicated.
23. PITCH SLIDER - This slider is used to adjust
the playback pitch percentage when the
PITCH
(7) function is activated. The slider is a set
adjustment and will remain set until the pitch
slider is moved or the
PITCH (7) function has
been turned off. This adjustment can be made
with or without a CD in the drive. The pitch
adjustment will remain even if a disc has been
remove, and will reflect on any other disc loaded
into the unit. That is to say, if you set a +2%
pitch on one disc, remove that disc and insert
