Outback Power Systems GS3548E Operators Manual - Manual (Page 71)

Specifications
900-0145-01-01 Rev A 69
Table 16 Radian Inverter Settings
Field Item Default Minimum Maximum
Inverter Stacking Stack Mode Master Master, Slave, B Phase Master, C Phase Master
Power Save
Ranking
Mode = Master: Master Power Save Level 0 0 31
Mode = Slave: Slave Power Save Level 1 1 31
Mode = B Phase Master Master Power Save Level 0 0 31
Mode = C Phase Master: Master Power Save Level 0 0 31
Grid-Tie Sell
Grid-Tie Enable Y Y or N
Sell Voltage 52.0 Vdc 44.0 Vdc 64.0 Vdc
Module Control Module Control
GS7048E Auto Auto, Left, Right, Both
GS3548E Left Auto, Left, Right, Both
Calibrate
Grid AC Input Voltage X 0 Vac –7 Vac 7 Vac
Gen AC Input Voltage X 0 Vac –7 Vac 7 Vac
Output Voltage X 0 Vac –7 Vac 7 Vac
Battery Voltage X 0.0 Vdc –0.8 Vdc 0.8 Vdc
Grid Interface Protection Menu
Operating Frequency Operating Frequency X 50 Hz 50 Hz, 60 Hz
Stage 1 Voltage Trip Over Voltage Clearance Time X 1.5 seconds 0.12 seconds 4.0 seconds
Over Voltage Trip X 252 Vac 240 Vac 300 Vac
Under Voltage Clearance Time X 1.5 seconds 0.12 seconds 4.0 seconds
Under Voltage Trip X 208 Vac 160 Vac 240 Vac
Stage 2 Voltage Trip Over Voltage Clearance Time X 0.2 seconds 0.12 seconds 4.0 seconds
Over Voltage Trip X 264 Vac 240 Vac 300 Vac
Under Voltage Clearance Time X 0.2 seconds 0.12 seconds 4.0 seconds
Under Voltage Trip X 196 Vac 160 Vac 240 Vac
Frequency Trip Over Frequency
Clearance Time
X 0.2 seconds 0.12 seconds 5.0 seconds
Over
Frequency
Trip
50-Hz system
X
51.0 Hz 50.1 Hz 55.0 Hz
60-Hz system 61.0 Hz 60.1 Hz 65.0 Hz
Under Frequency
Clearance Time
X 0.2 seconds 0.12 seconds 5.0 seconds
Under
Frequency
Trip
50-Hz system
X
47.0 Hz 45.0 Hz 49.9 Hz
60-Hz system 57.0 Hz 55.0 Hz 59.9 Hz
Mains Loss
Clearance Time X 2.0 seconds 1.0 seconds 5.0 seconds
Reconnect Delay X 300 seconds 2 seconds 302 seconds
Sell Current Limit
Maximum
Sell Current GS7048E
X
30 Aac 5 Aac 30 Aac
GS3548E 15 Aac 5 Aac 15 Aac
