Operation
42
In Table 4, instead of loads, the number on the far left of each line shows the master increased by one
rank. (This example is otherwise the same as Figure 13.)
The last line of the table shows the master increased to 3, which is the same as the rank of the highest
slave. However, this only activates the first of the three slaves. The master would need to be set to
rank 7 to activate all slaves.
Table 4
Changing Master Power Save Levels (GS7048E)
Master
Slave 1
Slave 2
Slave 3
Power
Save
Module
1
Module
2
Power
Save
Module
3
Module
4
Power
Save
Module
5
Module
6
Power
Save
Module
7
Module
8
0
On
Off
1
Off
Off
2
Off
Off
3
Off
Off
1
On
On
1
Off
Off
2
Off
Off
3
Off
Off
2
On
On
1
On
Off
2
Off
Off
3
Off
Off
3
On
On
1
On
On
2
Off
Off
3
Off
Off
