7.2 Connecting the DVR to a TV or Monitor
Using the supplied VGA connector:
1. Connect the VGA connector to the back
of the DVR’s VGA port.
2. Connect the other end of the cable to an available VGA input on
your TV or monitor.
3. Select the appropriate video input channel on your TV or monitor to
view the DVR.
Note: If your TV does not have a VGA port, you will need to purchase a
BNC-to-RCA
video cable. Attach the cable’s yellow RCA video connector
to a yellow Video Input port on your TV, and the cable’s BNC video
connector to the Video Out (V-OUT) port on the back of the DVR.
