Mounting the ½ Ladder Rack
Note: This illustration shows installation on the passenger side for the front leg. If installation is
intended for the driver saide, simply reverse the parts
Note: If your pick up has a bed liner, you may need to trim, drill, or cut the liner for proper and
secure installation of the ½ ladder rack
Note: If the best mounting hole location is between floor spacer and/or extra 5/16” flat
washers have been provided to fill the void or rotate the leg socket 90 degrees to the rear of
the vehicle if possible.
Step 1: Drill ½” hole for the blind fastener. Place a drop of oil on the black oxide bolt before
assembling as shown above. Place the blind fastener in the hole and use a ½” or 4/16” wrench
to tighten black hex bolt until the blind fastener is fully sealed. When setting the black hex bolt,
it will start out hard, as the blind fastener “bulbs out” it will get easier. Note: Make sure that
the blind fastener and Installation tool does not turn during installation.
Step 2: Install the Rope Cleat. The two rope cleats are to be mounted where desired.
Step 3: Place a ladder on the rack and check door entry/head clearance. If there is ample
clearance, and if desired, the rack lets may be shortened as long as a minumum clearance of 2”
about the cab with the ladder is maintained. Remove and cut the legs if desired. Note: cut the
tubing from the bottom of the legs. Double check the measurement before cutting.
WARNING: FAILURE TO FOLLOW OR COMPY WITH ALL THE WARNING AND INSTRUCTIONS IN
THIS MANUAL MAY RESULT IN EQUIPMENT DAMAGE OR SERIOUS BODILY INJURY.
WARNING: OUR LADDER RACK IS ONLY INTENDED AND ONLY SAFE FOR TRANSPORTING
LADDER, LUMBER, PIPES, AND OTHER SIMILAR MATERIALS. IT IS THE USER’S RESPONSIBILITY TO
ENSURE THAT THE MATERIALS BEING TRANSPORTED IS SAFELY SECURED ON THE RACK BEFORE
TANSPORTATION. ANY USE OF THIS PRODUCT FOR OTHER PURPOSES OR MODIFICATIONS
MADE TO THIS PRODUCT CAN CAUSE SERIOUS BODILY INJURY OR PROPERTY DAMAGE.
WARNING: LADDERS MUST BE SECURED PER ANSI STANDARD A 14.2-1990 PARAGRAPH 8.4.4
LADDER DAMAGE WILL OCCURE FROM ROAD SHOCK AND VEHICLE VIBRATION IF THE LADDER
IS NOT PROPERLY SECURED TO THE LADDER RACK. BOUNCING AND SIDE TO SIDE MOTION OF A
