Dee Zee FX22979 - Manual (Page 3)

Page 3 of 11
FX 22979 04/13/09
FX 22979, FX 22379
(2009 – Current) Ford F150 8’ Box Pickup
v
Driver Side-Rear Brace E Angle bracket
¼ flat washer
Side Box Boards
D F
X2
Driver Side-Front Brace
B
X1
Passenger Side-Rear Brace
X12
Passenger Side-Front Brace
X1
C
X1 X1 X4
Fin Gasket ¼ X 1 Slotted
Head Bolt
K
X6.25Ft X8
L M
BD 22969 / BD 22369 B 1330LP B 1330RP
B 1329LP B 1329RP B 1332
GSK-15 PN 86A PN 72
N
A
H G I
Support Bracket
B 1726P X2
Angle Bracket
B 1331P X2
Mud Flap Kit
MXFLSL-3.5
MXFLSR-3.5
X1L/X1R
J
End Cap Kit
MXFLSL /R X1L/X1
PN 140
X8
#10 Phillips
head screw
