WRENCH/RATCHET
3/8", 7/16"

TAPE

MEASURE

CLAMP

3/16" DRILL BIT
1/4" DRILL BIT

Pre-assemble the end cap [B] and strap bracket [C] using two hex head bolts [G], four washers [H],
and two nuts [I]. Leave the parts somewhat loose for the next step.

TOOLS REQUIRED

Slide the pre-assembled end cap into the end of the board until the end cap is flush with the
end of the board. The end cap must be inside the board and the strap bracket outside the board.
Tighten the bolts with a 7/16" wrench and socket.

Repeat for the other end of the board.

DZ 2544

2 OF 8

2/12/2013
